FP215KWH-100KW Standard Energy Storage Cabinet
Key:
FP215KWH-100KW Standard Energy Storage Cabinet
Category：
Industrial and Commercial Energy Storage Systems
Email: info@newpower-tech.com
| Model Number: | FP215KWH |
| Product Model | CT-ES-215/AC |
| Cell Type | LFP-280Ah |
| System Configuration | 1P240S |
| Battery Capacity | 215KWH |
| Battery Voltage Range | 672-864V |
| Temperature Control Method | Liquid cooling |
| Grid Type | 3P3W |
| Rated Power | 100KW |
| Rated Grid Voltage | 400VAC(340~440V) |
| Power Factor Adjustable Range | -1~1 |
| Grid Frequency | 50Hz/60Hz |
| Rated Current | 250A |
| Dimensions(L*D*H) | 1500*1450*2250mm |
| Communication Method | CAN/RS485/Ethemet |
| Weight | 2000kg |
| Protection Level | IP54 |
| Operating Temperature | -20~55°C |
| Cooling Method | Liquid cooling for battery compartment, air cooling for electrical compartment |
About this product
● OEM WELCOME
● SKD SERVICE
● ODM ACCEPTABLE
